12
CABLE AND HOOK ASSEMBLY
P/N 18031
ITEM PART DESCRIPTION QTY. ITEM PART DESCRIPTION QTY.
1 15889 SHEAVE 10620 9.25 DIA .44R/1.94 THK 1 11 15997 WIRE ROPE .44 6X25 IWRC-XIP 100FT 1
2 16000 PLATE 10620 SNATCH BLOCK 2 12 11938 SWITCH LIMIT A2B FURNAS 3SE3170 1
3 13394 SPACER 9620 SNATCH BLOCK 3 13 12177 CAP SCR #10-24 X 1.50 SHGR5 4
4 C1030 CAP SCR 0.75-10X5.00 HHGR8 3 14 D1711 CAP SCR #10-24X0.50 BTNHD SS 1
5 C6219 WASHER 0.75 SAE FLAT YELLOW GR8 3 15 C4956 NUT #10-24 HH NYLOC SS 1
6 0538 NUT 0.75 HHGR8 NYLOC 3 16 19994 WEIGHT 3315 ATB 1
7 13399 PIN TEAR DROP 1.00X3.81 1 17 0530 CAP SCR 0.38-16X2.75 HHGR5 1
8 0343 WASHER 0.31 FLAT 1 18 0347 NUT 0.38-16 HH NYLOC 1
9 0420 CAP SCR 0.31-18X0.75 HHGR5 1 19 18454 Chain 0.105 X 19.00 1
10 13436 PIN .38X4.00 QUICK RELEASE 1 20 3863 HOOK 5 TON 1
