84
650/800/850 GUEPARD
COOLING AGENT
Cooling agent
The cooling agent level should be checked before
every trip. Besides, the cooling agent should be
replaced at the intervals indicated in the regular
maintenance and lubrication table.
To check the cooling agent level
1. Park the vehicle on a flat horizontal surface.
2. Open the decorative hood panel fixing device
and shift the panel forward till the back guides
disengage. Remove the panel.
1. The decorative plate fixing device
3. If the cooling agent level is under the lower mark,
remove the expansion tank cover, fill up the
cooling agent to the maximum mark and close
the cover.
1. Maximum mark
2. Minimum mark
4. The cooling agent level in the expansion tank
should be checked with cold engine as it changes
depending on the engine temperature.
Coolant expansion tank volume
(up to the maximum level mark): 0.3l
