11 List of spare parts
© F. Stephan GmbH SA-103-0109V1.3-HAO-GB 47
Fig. 22: spare parts spindle
Fig. 23: spare parts spindle
The parts listed below must be exchanged on occasion of the prescribed
semi-annual servicing.
Item Designation Article No.
1 Packing inset for spindle 1 150 40 014
2 O – ring 3 x 1 1 950 60 001
Latching device, type Vapo – Typ TEC 4
3 O – ring 6 x 1,8 1 950 60 027
Tab. 15: spare parts spindle
