StepperOnline BLD-510B - Terminal Connection

BLD-510B BLDC B r u s h l e ss Driver
4
3. Terminal Connection
3.1 Power Input
No.
Terminal Name
Description
1
V+
24VDC~48VDC input
2
GND
GND input
3.2 Motor Input
No.
Terminal Name
Description
1
MA
Motor A phase
2
MB
Motor B phase
3
MC
Motor C phase
4
GND
GND
5
HA
Hall signal A phase input
6
HB
Hall signal B phase input
7
HC
Hall signal C phase input
8
+5V
Hall signal power line
3.3 Control the Signal
No.
Terminal Name
Description
1
GND
Signal ground
2
F/R
CW/CCW terminal
3
EN
Stop/Start terminal
4
BK
Brake terminal
5
SV
Analogy signal input terminal
6
PG
Speed output terminal
7
ALM
Alarm output terminal
8
+5V
+5V power output terminal
Indicator P/A: The green light is the running light, and the motor is always on; The red light is the alarm indicator,
and the driver alarm is always on.
Communication port: RS485 two-wire serial link communication, you can communicate with the connection control
or connect with the computer to modify parameters.
Built-in p otentiometer R-SL : Adjust the motor speed gain, which can be adjusted from 0~100%.
The factory set maximum speed is brushless motor 1 pairs of pole 14000 RPM, 2 pairs of pole 7000 RPM, 4
pairs of pole 3500 RPM, 5 pairs of pole 2800 RPM. If the maximum speed is required to exceed the factory set
speed, please contact us to change the internal jumper of the drive.
Built-in potentiometer R-CS: Maximum protection current setting, built-in potentiometer can be set 0%~100%
continuous current protection.
