15
13406 SE 32nd St, BELLEVUE WA, 98005 WWW.CONSUMER.STEPPIR.COM TEL: (425)-453-1910
2E With 40m-30m Dipole Kit
(not to scale)
2E Without 40m-30m Dipole Kit
(not to scale)
Figure 1.03
Boom / Mast Plate
Mast
6m Passive 114 in. long
Splice
Director Driven
22 in. from center of driven element
to center of 6m passive element
57 in.
Boom / Mast Plate
Mast
6m Passive
114 in. long
Splice
Director Driven
22 in. from
center of driv-
en element to
center of 6m
passive ele-
ment
57 in.
ANTENNA OVERVIEW AND DIAGRAM
Figure 1.04
*Not to scale
To Next Page
