It is important that you do an inventory of the items that were shipped to you. We do our
very best to ensure that you receive everything needed for construction of your antenna, but
better to be safe than sorry—inventory your parts well in advance of your installation. The items
in blue represent hardware for the 40/30 loop—you will not need to check these off if your an-
tenna does not include the 40/30 loop.
What Comes in the Antenna Box
✓ QTY PART #
DESCRIPTION
1 09-0001
Electrical tape 3/4” PVC MERCO 307
1 09-1025
Conical Grinding Stone, 3/4”
4 OR 6 10-1013-02
Telescoping Pole, 18 foot 4 section
1 10-1028-21
TM-1 Thread Magic Anti-seize sticks
1 10-1054-02
Truss support, 30m/40m, 36”
8 OR
12
10-1059-01
Polyolefin Heat Shrink 1-1/2” x 6”
4 OR 6 10-1059-21
Polyolefin Heat Shrink 1.1” x 6”
2 10-1501-23
Cover for Black EHU, With countersunk drain hole
2 10-1509-02
Diverter Cone
1 21-6040
Splitter, 6” 3-1/2mm, Stereo Male to Two RCA Female
4 OR 6 60-1006-22
QUICK DISCONNECT, 1.75" to 1.5", Fernco (STANDARD)
4 OR 2 70-1007-01
Foam plug assembly consisting of plastic cap and foam plug
1 70-1508-02
Boom assembly, 2 Element
2 70-2025-13
CPVC tube, 49” x 3/4”, with coupler
2 70-2025-23
CPVC tube, 39-7/8” x 3/4”, without coupler
1 70-2034
Connector Junction Box, 2E and 3E
1 70-3000-01
33 Volt supply with cord
1
70-3401-01 OR
70-3403-01
EHU, 20m Driven OR 40m Driven
1 70-3420-01
EHU, 20m Passive
1 70-6010-01
Adapter, 25pin Dsub Field Splice
1 72-0009-03
Kit, Glue
1
72-0010-01 or
-02
Kit, UrbanBeam/2E EHU Cable Assemblies and 16” Coax Seal (72-0010-
02 is preassembled, 72-0010-01 is bare cable only)
2 72-0054-01
Kit, EHU Lid Hardware - 1 for Driven and 1 for Passive
1 70-6002-01
2E 6m Passive element
1 72-0014-01
Kit, 2E/3E 6m hardware
1 09607
High Wind Mast Kit; 2 or 3 element Yagi
1 -
QR Code Sheet - Instruction Manuals
PARTS CHECKLIST
