Section 1.2: EHU assembly
ASSEMBLY
Key QTY Part Number Description
A 1 - EHU, BigIR (with control cable & coax seal)
B 1 10-1501-22 Cover for EHU, no drain hole
C 1 10-1502-12 EHU Gasket
D 4 60-0017 Pan Screw, 10-32 x 3/4”
E 1 60-0017-10 Flat Head Screw, 10-32
F 5 60-0019 Nut, 10-32, Nylock
G 4 60-0018 Washer, 10-32, Flat
A
B C
D
E
F
G
Use anti-seize on
all SS hardware!
Do not install if
using 80m coil
