COMMISSIONING REPORT
BEFORE MEASURING DATA:
Correct level of operating fluids (motor oil, gear oil, hydraulic oil, cooling agent) confirmed yes
Leakage (oil, fuel, coolant) checked ok if not detail:
*) HYBRID
full filled STEYR MOTORS Dealer Check List (find in Hybrid Operation, Maintenance and Warranty
Manual) and send signed document to STEYR MOTORS GENERAL
Max. Voltage supply from Hybrid-battery bank to HCU(≤57 V): V
MEASURING DATA:
Max. boat speed: knots Fuel flow amount on return-line in idle: l/min
Max. engine-rpm by WOT (CMD=5) rpm Motor oil pressure (SMO-EDT): bar
Idle speed: rpm Engine coolant temp. (SMO-EDT): °C
Temperature engine compartment: °C Exhaust raw water temp. (SMO-EDT): °C
Exhaust backpressure: mbar Boost-pressure at max. rpm (SMO-EDT): mbar
Active engine warnings: YES NO if YES which:
Instruments adjusted: YES
LOG FILE (Idle – Full Load – Idle) name:
*) HYBRID
Max. boat speed in E-Mode: knots
– with Speed Mode: low mid1 mid2 high
– max. engine rpm achieved in E-Mode: rpm
D-Mode status on SCC E-Mode ready-red, D-Mode ready-green, HCU-Mode ready-green, GENERATOR YES
(see SCC User Manual Z001071-0; chapter Hybrid menu)
NOTES:
E-Mode status on SCC E-Mode ready-green, D-Mode ready-red, HCU-Mode ready-green, E-Drive YES
(see SCC User Manual Z001071-0; chapter Hybrid menu)
NOTES:
Flow-rate through Hybrid cooling-system: l/min (see in Hybrid cooling schematics mentioned above)
Max. HCU temperature on SCC: °C (see SCC User Manual Z001071-0; chapter Hybrid menu)
Max. E-MOTOR temperature on SCC: °C (see SCC User Manual Z001071-0; chapter Hybrid menu)
Safeguarding instruction carried out YES
Manual, warranty and operation explained YES
Test made on: , by
(Name in block letters)
Please immediately return a copy of this report and the Warranty registration card to your
STEYR MOTORS GENERAL DISTRIBUTOR. Failure to do say may affect factory warranty.
