STEYR MO256H45 User Manual

58
fullload
speedrange
100%
90%
80%
70%
60%
50%
40%
30%
B
C D
RPM
A
OUTPUT
POWER
Technical Data and overview MO286H43, MO156K25, MO126K25
MAKE STEYR MOTORS M 16 TCAM
type MO286H43 MO156K25 MO126K25
displacement 3,200 cm³
piston displacement 85.0 x 94.0 mm
rated power acc. EN ISO 8665:2006
(impeller*) KW/HP
Jet – Drive/Inboard
Z – Drive
199/270
196/266
107/145
105/143
85/116
84/114
number of cylinders 6-cylinder in-line engine (position of cyl. 1 at vibration damper side)
ignition order 1 – 5 – 3 – 6 – 2 – 4
sense of rotation, seen from front right
compression ratio 17.0:1
full-load speed range (rpm)
4,300 rpm
(+0 rpm/–300 rpm)
2,500 rpm
(+0 rpm/–200 rpm)
2,500 rpm
(+0 rpm/–200 rpm)
idle speed 630 rpm (adjustable)
injection Plunger activated, two stage, high pressure with electronically
controlled injection rate
fuel acc. to CEC RF-03-A-84 (DIN 51601) Cetan >45; diesel fuel
No. 2-D, temperature above –7 °C; No.1-D, temperature below
–7 °C
fuel filter refer to spare part catalogue
fuel filter location intake-sided
air filter refer to spare part catalogue
oil pressure above 2,000 rpm 400 – 700 kPa (58 – 101 PSI) microprocessor controlled
filling capacity motor oil approx. 12.0 l engine housing (incl. approx. 1 l oil filter contents)
specification motor oil SAE 5W-50/ACEA B4-02/API CF or 10W-40/ACEA E4, E5,
E7/API CF P/N0. Z010058/0
oil and oil filter change intervals**) every 150 operating hours and/or once per season
oil filter refer to spare part catalogue
oil filter location pressure-sided
electric charging system 14 V/90 A alternator with transistorized voltage regulator
cooling system dual cooling circuit; thermostat-controlled, pressurized cooling
circuit; circulating pump with heat exchanger on engine; governor
pump, external raw water circuit to heat exchange
coolant capacity 13.2 liters
coolant STEYR MOTORS engine coolant –36 °C
P/No. Z011785/0
*) Efciency of gearbox = 97.0 %, efciency of Z-Drive = 95.5 %
**) Extended periods to be evaluated upon application and type of usage STEYR MOTORS GmbH.
Reserves the right to make changes without notice or obligations.
MO286H43
MO156K25
MO126K25

STEYR MO256H45 Specifications

General

Brand	STEYR
Model	MO256H45
Category	Engine
Language	English
