STEYR MO256H45 - Instrument Panel

26
B
A
E
D
F
H
G
J
A1
I
C
A1
Instrument panel
Instrument panel, standard
A tachometer F ignition key
A1 function buttons G blind plug – installation option for
key switch constant revolution
B engine parameter display
C warning light – battery charge H audible warning device
(installed on rear side of panel)
D
combined light preheating control &
warning light engine oil pressure
I emergency cut off switch (lanyard)
E warning light check engine J circuit breaker (10 amp)
If you should need additional instruments or accessories, please contact your STEYR MOTORS Marine dealer.
