STIEBEL ELTRON DHC 6 XG - Unit Installation Procedure

STIEBEL ELTRON
14
- Insert the cable through the rubber
seal at the rear of the unit. Please
the mains.
4.2 Installation the unit
Preparation before installation of the
unit:
water heater.
4. Installation Instruction
- Place a drilling guide at the drilling
position in order to drill a hole in the
wall (Fig 6).
- Insert a wall plug and screw in (the
depth of the protruding screw head
must be correct) (Fig 6#3).
- Remove the screw from underneath
the water heater
- Open the cover of the unit.
- Remove the plug connecting the
cover of the unit.
Fig 9
Fig 10
Fig 11
Fig 12
