STIEBEL ELTRON wpf 20

8.5 Fitting the casing parts
H
Fitting the plinth facia and control panel frame
1
2
1
C26_03_01_0791
2
1.
3.2.
»Hook the plinth facia 1 into the device frame and secure each with three screws
»Position the covers 2 and secure each with two screws to the sides.
I
Fitting the side covers
C26_03_01_0792
2
1
»
Fix the guard plate 1 with four screws. The both in the front with the toothed locked washer.
»Secure the control panel frame 2 with five screws.
12 | WPF 20/27/40/52/66 www.stiebel-eltron.com
