STIHL 020 T 51
• Position end cover on carburetor
body so that peg (1) engages the
bore (2).
• Insert screws and tighten down
firmly.
• Fit the end cover.
• Insert screws and tighten down
firmly.
Note: The pump diaphragm and
gasket are held in position by inte-
grally cast pegs on the end cover.
• Remove the E-clip.
• Insert the fuel strainer at the
pump side.
• Fit the pump diaphragm.
Removing the throttle shaft
• Unscrew the throttle shutter
fastening screw.
• Take out the throttle shutter.
• Pull out the throttle shaft.
• Remove the torsion spring.
• Disconnect the torsion spring
(1) from the groove in the throttle
shaft (2).
• Place gasket on pump
diaphragm.
