:DUPVWDUWSRVLWLRQ
Choke shutter is open - throttle trigger is
in starting-throttle position.
If you leave the Master Control lever
in the cold start position, the combustion
chamber will flood and stall the engine.
The Master Control lever must be in
warm start position to start a warm
engine. Also select this position if engine
has been running but is still cold.
The Master Control lever should not be
forced to Run position - it will move
to the Run position as soon as the
throttle trigger is activated.
In the warm start position, continue
cranking after engine begins to fire.
As soon as the engine runs,
LPPHGLDWHO\ blip the throttle trigger
so that the Master Control lever moves
to Run - this is the idling or normal
operating position .
To turn off the engine:
Move the Master Control lever upward
to STOP position :
The stop contact should engage the
contact spring - this cuts out the ignition
system.
2QO\PDFKLQHVZLWK
GHFRPSUHVVLRQYDOYH
•
Press in the button.
Compression pressure is released
when the button is pressed in.
This helps reduce the effort
required to pull the starter rope.
The valve closes automatically
as soon as the engine fires.
•
For this reason the button should
be pressed in before each starting
attempt.
$OOYHUVLRQV
•
Observe safety precautions -
see chapter "Safety Precautions".
•
Push hand guard  forward
to lock the chain.
•
Press down the throttle trigger
interlock  and set Master
Control lever to:
For cold start O
For warm start Q
(even if engine has
been running but is still cold)
133BA001 K
2
1
0
STOP
143BA017 KN
6WDUWLQJ
46 
