When starter rope is fully extended
it must be possible to rotate the
rotor at least another half turn. If
this is not the possible, the spring
is overtensioned and could break.
Take off one turn of the rope.
•
Fit the fan housing on the
crankcase.
•
Set the Master Control lever to E
•
Push the remaining rope into the
starter grip so that the nipple
is flush with the grip.
5HSODFLQJDEURNHQUHZLQGVSULQJ
•
Lubricate the new spring with a few
drops of non-resinous oil.
•
Remove the rope rotor-
see "Replacing Starter Rope".
•
Remove the spring housing and
parts of spring.
•
Fit the new spring housing -
bottom plate must face upward -
slip outer spring loop over lug.
•
Reinstall the rope rotor, tension the
rewind spring, fit the fan housing
and secure in position.
•
If the spring pops out of its housing
during installation: refit it in the
counterclockwise direction, starting
outside and working inward.
001BA007 K
8
46
