Stihl ADG 1 - Storing the Analyzer; Storage Procedures; Main Parts; Component Identification

ADG 1
English
9
N Remove the battery.
N Disconnect the plug from the wall
outlet.
N Disconnect USB cable from
analyzer.
N Store in a dry, locked location. Keep
it out of the reach of children and
other unauthorized persons and
protected from contamination.
1 Battery analyzer
2 Power cord
3 Light emitting diode (LED)
4 Button
5 Display
6 USB
-
interface
7 Contacts
8 USB cable
# Rating plate
Battery
The unit can be operated only with
STIHL rechargeable batteries.
Storing the Analyzer Main Parts
6
1
2
3
4
5
#
4901BA017 KN
7
8
Specifications
Power supply: 120 V
Frequency: 60 Hz
Power consumption: 28 W
Insulation: II, E
Model: Lithium-ion
