FS 250, FS 250 R
English
25
Balancing the Machine
The unit is balanced differently
depending on the cutting attachment
used.
Proceed as follows until the conditions
specified under "Floating positions"
have been met:
N Loosen the screw (1).
N Slide the carrying ring (2) along the
drive tube.
N Tighten the screw moderately.
N Allow the unit to hang freely.
N Check the position obtained.
Balanced positions
Mowing tools such as mowing heads,
grass cutting blades and brush knives
N should just touch the ground.
Circular saw blades
N should "hover" about 20 cm (8 in)
above the ground.
When the correct floating position has
been reached:
N Tighten down the screw on the
carrying ring firmly.
Controls
Control handle on handlebar
1 Throttle trigger lockout
2 Throttle trigger
3 Slide control
Balancing the Machine
Starting / Stopping the
Engine
START
3
STOP
5 6
4
7
002BA668 KN
1
2
