33FS 45, FS 46
English
: Straighten out the nylon lines and
wind them tightly onto the spool –
one nylon line in each chamber.
: Engage the ends of the nylon lines
in the notches (5).
Assembling the Mowing Head
Check that the compression spring
is installed (see “Mounting the
Mowing Head”).
: Thread the ends of the lines (6)
through the sleeves (7) and push
spool (2) into the head so that it
snaps into position.
Nylon lines must disengage from
notches (5) as the spool is pushed
into position.
: Pull out the ends of the lines as far
as stop.
: Mount the mowing head on the
machine.
681BA010 KN
5
5
7
681BA011 KN
2
6
6
