130 FS 240 C, FS 260 C, FS 360 C, FS 410 C, FS 460 C-M
No. Designation Part No. Use Re-
marks
9 Assembly drift 1110 893 4700 Removing and installing piston pins
10 Combination wrench 1129 890 3401 Spark plug 1)
11 Installing sleeve 4119 893 4600 Protection of the oil seal
(Starter side)
12 Press arbor 4119 893 7200 Cold forcible insertion of starter side
ball bearing
13 Installing tool 4126 893 4900 Rubber element 1-point antivibration
system
14 Clamping device for assembly
stand
5910 890 8800 Clamping drive tube assembly of
machine to assembly stand
15 ZAT 4 ignition tester 5910 850 4503 Test ignition system
16 ZAT 3 ignition tester 5910 850 4520 Test ignition system
17 Torque wrench 5910 890 0302 Screw connections (0.5 to 18 Nm)
18 Torque wrench 5910 890 0312 Screw connections (6 to 80 Nm)
19 Installing tool, 11 5910 890 2211 Fit hookless snap rings in piston
20 Bit T 27 x 150 5910 890 2400 IS-P screws (4 mm)
21 Assembly stand 5910 890 3101 Holding machine for repairs
22 Puller 5910 890 4400 Extracting the oil seal
- Jaws (with profile no. 3.1) 0000 893 3706 Extracting oil seal(s)
23 Assembly hook 5910 893 8800 Remove pick-up body
Remarks:
1) Use only for releasing.
