Stihl FS 56 C-E User Manual

FS 56, FS 56 R, FS 56 C, FS 56 RC
English
26
N Turn the cap counterclockwise
(approx. 1/4 turn).
N Remove fuel filler cap.
Refueling
Take care not to spill fuel while fueling
and do not overfill the tank. STIHL
recommends use of the STIHL filling
system (special accessory).
Closing the toolless filler cap
With grip in an upright position:
N Insert the cap – positioning marks
on the cap and the fuel tank opening
must line up.
N The cap should drop fully into the
opening in this position.
N While pressing the cap down, twist it
firmly clockwise as far as it will go
(approx. 1/4 turn).
N Fold down the grip.
Checking for proper closure
N The lug on the grip must engage
entirely in the recess (arrow), and
the grip must lie completely flush
with the top of the cap.
N Grip the cap and check for
tightness.
N If the cap can be moved, it is not
properly installed.
Misalignment of the cap parts
N If the cap does not drop fully into the
opening when the positioning marks
line up and/or if the cap does not
tighten properly when twisted, the
base of the cap may be rotated out
of position vis-à-vis the top.
N Such misalignment can result from
handling, cleaning or an improper
attempt at tightening.
001BA219 KN
001BA224 KN
001BA220 KN
001BA221 KN
001BA222 KN
001BA223 KN
001BA225 KN
