FS 56, FS 56 R, FS 56 C, FS 56 RC
English
41
3. Line Limiting Blade
Metal blade at the deflector in order
to keep the line of the mowing head
at the proper length.
4. Deflector for Grass Cutting Blades
The deflector is designed to reduce
the risk of injury from foreign objects
flung backwards toward the
operator by the cutting attachment
and from contact with the cutting
attachment.
5. Grass Cutting Blade
The grass cutting blade made from
metal for different purposes (special
accessory).
EPA / CEPA
The Emission Compliance Period
referred to on the Emissions
Compliance Label indicates the number
of operating hours for which the engine
has been shown to meet Federal
emission requirements.
Category
CARB
The Emission Compliance Period used
on the CARB-Air Index Label indicates
the terms:
Engine
Ignition System
Electronic magneto ignition
Fuel System
All position diaphragm carburetor with
integral fuel pump
Weight
Specifications
A = 300 hours
B = 125 hours
C = 50 hours
Extended = 300 hours
Intermediate = 125 hours
Moderate = 50 hours
Single cylinder two-stroke engine
Displacement: 1.66 cu. in.
(27.2 cm
3
)
Bore: 1.34 in. (34 mm)
Stroke: 1.18 in. (30 mm)
Engine power to
ISO 8893:
1.1 hp (0.8 kW)
at 8,500 rpm
Idle speed: 2,800 rpm
Cut-off speed (rated): 10,000 rpm
Max. output shaft
speed (cutting
attachment): 8,100 rpm
Spark plug (resistor
type): NGK CMR 6 H
Electrode gap: 0.02 in.
(0.5 mm)
Fuel tank capacity: 11.5 fl.oz (0.34 l)
Standard versions
dry, without cutting attachment and
deflector
FS 56: 11.3 lbs. (5.1 kg)
FS 56 R: 10.4 lbs (4.7 kg)
