42
English / USA
FS 80, FS 80 R, FS 85, FS 85 R
To reduce the risk of fire and burn
injury, use only spark plugs
authorized by STIHL. Always press
spark plug boot (2) snugly onto
spark plug terminal (1) of the proper
size. (Note: If terminal has
detachable SAE adapter nut, it must
be attached.)
A loose connection between spark
plug boot and ignition wire
connector in the boot may create
arcing that could ignite combustible
fumes and cause a fire.
: Check grease level regularly - about
every 25 hours of operation.
: Unscrew the filler plug (1).
: If no grease can be seen on the
inside of the filler plug, screw the
tube (2) of STIHL gear lubricant for
brushcutters - see “Special
Accessories” - into the filler hole.
: Squeeze up to 1/5 oz (5 g) grease
into the gear housing.
Do not completely fill the gear
housing with grease.
: Refit the filler plug and tighten it
down firmly.
Removing the Starter Cover
: Take out the screws (1).
: Lift the starter cover (2) away from
the tank (3) and pull it out from
under the shroud (4).
00BA036 TR
1
Lubricating the
Gearbox
1
233BA010 KN
2
Replacing the Starter Rope
and Rewind Spring
1
1
1
2
3
4
392BA013 KN
