0458-698-0121-A
20
English
8 Removing and Fitting the Battery
► Press the oil tank cap down and rotate it clockwise as far
as it will go.
The oil tank cap snaps into place. The mark (1) points to
mark (3).
► Check to see if the oil tank cap can be pulled upwards and
off.
► If the oil tank cap cannot be pulled upwards and off: Fold
down the grip on the oil tank cap.
The oil tank is closed.
If the oil tank cap can be pulled upwards and off, perform the
following steps:
► Place the oil tank cap in the filler opening – in any position.
► Press the oil tank cap down and rotate it clockwise as far
as it will go.
► Press the oil tank cap down and rotate it counterclockwise
until mark (1) points to mark (2).
► Now try again to close the oil tank.
► If the oil tank still cannot be closed properly: Do not use
your pole pruner and contact a STIHL dealer for
assistance.
The pole pruner is not in a safe condition.
8.1 Inserting the Battery
► Insert the battery (1) up to the limit stop into the battery
compartment (2).
The battery (1) engages with a click and is now locked.
8.2 Removing the Battery
► Place the pole pruner on a level surface.
► Press both locking levers (1).
The battery (2) is released and can be removed.
8 Removing and Fitting the Battery
1
2
0000097033-001
2
1
0000097034-001
