67MS 210, MS 230, MS 250
Fuel tank and engine housing are a
single unit.
– Remove the engine – b 8.
– Remove the chain tensioner –
b 8.
– Remove the chain brake –
b 8.
: Disconnect the short circuit
wire (1).
: Take out the screws (2).
: Remove the ignition module (3).
VA
135RA225
2
1
3
2
: Unscrew the fuel filler cap and
remove with cap retainer, if fitted.
: Use hook (1) 5910 893 8800 to
pull pickup body out of the fuel
tank.
Do not stretch the suction hose.
VA
208RA105
1
: Pull the pickup body off the hose.
VA
208RA106
– Pry the suction hose flange out of
the fuel tank.
: Pull out the suction hose.
VA
208RA107
: Pull out the oil pump suction hose
with pickup body.
VA
135RA230
: Remove the spiked bumper, if
fitted.
VA
135RA233
11.8 Fuel Tank

Stihl MS 210 Specifications

General

Displacement	35.2 cm³
Bar Length	35 cm
Chain Oil Capacity	0.2 L
Chain Pitch	3/8"
Fuel Capacity	270 ml
