64 MS 650, MS 660
Removing at flywheel side
: Pry the plugs (arrows) out of the
annular buffers.
178RA086
VA
1
1
– Take the screws out of the
annular buffers.
: Pry the annular buffers (1) out of
the crankcase.
178RA087
VA
1
1
Note:
Coat annular buffers with STIHL
Press Fluid before installing.
Installing at clutch side
: Push the annular buffer (1) home
from outside so that its groove
engages the housing rib (2).
178RA092
VA
2
1
Installing at flywheel side
: Push the annular buffer home
from outside so that its groove (1)
engages the housing rib (2).
Reassemble all other parts in the
reverse sequence.
2
1
178RA091
VA
– Remove the crankcase from the
tank housing – b 12.10
: Take out the screws (1).
: Remove the annular buffer (2).
Reassemble in the reverse
1
178RA093
VA
2
sequence.
9.2 Annular Buffer at top of
Tank Housing
