73MS 650, MS 660
: Pull the heating element off the
studs.
All machines
178RA126
VA
: Pull the fuel hose (1) off the
carburetor.
178RA128
VA
1
: Remove the carburetor.
Reassemble in the reverse
sequence.
178RA127
VA
: Before fitting the carburetor,
check that the sleeve (1) and
washer (2) are in place.
1
2
178RA050
VA
: When pushing the carburetor into
position, check that the impulse
hose (1) is correctly seated.
: Connect the fuel hose (2).
178RA130
VA
1
2
: Squeeze the throttle trigger and
hook the rod (2) to the throttle
shaft (1).
178RA124
VA
2
: Fit the grommet so that the tabs
(1) engage behind the inside of
the housing.
– On machines with carburetor
heating, make sure that wiring is
properly positioned – b 15.2
178RA131
VA
