Stihl RB 400 - Specifications

RB 400
English
22
Definitions
1 Spray gun
Controls the high-pressure jet.
2 Coupling for high-pressure hose
To connect the high-pressure hose
to the spray gun.
3 Spray gun trigger
Opens and closes the valve in the
spray gun.
4 Trigger lockout
Blocks the Spray gun trigger.
5 Coupling for spray lance
To connect the spray lance to the
spray gun.
6 Spray lance
Directs the water from the spray gun
to the high-pressure nozzle
7 Coupling for high-pressure nozzle
To connect the high-pressure
nozzle to the spray lance.
8 High-pressure nozzle
Creates the form and intensity of the
high-pressure jet.
9 Pushbar
To push the pressure washer.
10 Holder for spray attachment
To store the spray attachment.
11 Star knob
To release and fold down the
pushbar.
12 Connector for water inlet with
screen
To connect the water hose to the
high-pressure pump. The screen
helps prevent dirt and debris from
entering the pump.
13 Suction hose for detergent
To draw detergent from a separate
container.
14 Connector for high-pressure hose
To connect the high-pressure hose
to the high-pressure pump.
15 On/Off Switch
To start/stop the engine.
16 Coupling on high-pressure hose
To connect the high-pressure hose
to the spray gun and to the high-
pressure pump.
17 High-pressure hose
Transports the water from the high-
pressure pump to the spray gun.
18 Holder for high-pressure hose
To store the high-pressure hose.
19 Holder for high-pressure nozzles
To store the high-pressure nozzles.
Engine
See engine instruction manual for
additional specifications.
High-pressure pump
Water supply
Specifications
Manufacturer: Kohler
Model designation: SH 265
Type: Single cylinder
four-stroke
engine
Fuel: Gasoline
Rated / Permissible
Pressure: psi 2700
MPa 19
bar 190
Maximum water
throughput: gpm 2.7
l/min 10.2
l/h 620
Maximum suction height
from a tank: ft. 2
m0.6
Maximum kickback force N 33.1
Diameter of water hose: in. 3/4
Maximum length of water
hose: m 15.25
ft. 50
Minimum quantity: gpm 3.7
