RE 109, RE 119, RE 129 PLUS
français
58
Caractéristiques hydrauliques
RE 109 RE 119 RE 129 PLUS
Pression de travail : 11 MPa (110 bar)
1) 2) 8)
12,5 MPa (125 bar)
1) 2) 8)
13,5 MPa (135 bar)
1) 2)
10 MPa (100 bar)
7)
8,2MPa (82bar)
3)
9,5 MPa (95 bar)
5)
8,4 MPa (84 bar)
5) 6)
8 MPa (80 bar)
4)
7,5 MPa (75 bar)
4)
7,2MPa (72bar)
3)
Pression max. admissible : 12 MPa (120 bar)
1) 2) 7) 8)
14 MPa (140 bar)
1) 2) 8)
15 MPa (150 bar)
1) 2)
10 MPa (100 bar)
3) 4) 5) 6)
10 MPa (100 bar)
3) 4)
11 MPa (110 bar)
5)
Pression max. d'arrivée d'eau : 1 MPa (10 bar) 1 MPa (10 bar) 1 MPa (10 bar)
Débit d'eau max. : 440 l/h
1) 2) 5) 6) 8)
500 l/h
1) 2) 8)
500 l/h
1) 2)
420 l/h
4)
430 l/h
3)
440 l/h
5)
510 l/h
7)
420 l/h
4)
380 l/h
3)
Débit d'eau selon la norme
EN 60335-2-79 : 380 l/h
1) 2) 8)
400 l/h
1) 2) 8)
420 l/h
1) 2
365 l/h
6)
360 l/h
3)
355 l/h
5)
360 l/h
4)
350 l/h
4)
355 l/h
3) 5)
420 l/h
7)
Hauteur max. d'aspiration : 1 m
1) 2) 7) 8)
1m
1) 2) 8)
1m
1) 2)
0,5 m
3) 4) 5) 6)
0,5 m
3) 4)
0,5 m
5)
Température max. d'arrivée
d'eau en alimentation en eau
sous pression: 4C 6C 6C
Température max. d'arrivée
d'eau en alimentation par
aspiration : 20 °C 20 °C 20 °C
Force de recul max : 15,6 N
1) 2) 8)
17,7 N
1) 2) 8)
19,2 N
1) 2)
13,2 N
6)
12,8 N
3)
13,6 N
5)
12,7 N
5)
12,2 N
4)
12,2 N
4)
11,8 N
3)
16,5 N
7)
