Stihl RE 128 PLUS User Manual

RE 108, RE 118, RE 128 PLUS
English
45
1 Spray gun
2 Lever
3 Safety catch
4 Trigger interlock
5 High-pressure hose
6 Spray lance
7 Fan jet nozzle, adjustable
8 Rotary nozzle
9 Spray set
10 Handle
11 Bracket for surface washing brush
12 Bracket for spray lance
13 High-pressure hose connection
14 Hose reel
15 Crank for hose reel
16 Bracket for cleaning pin
17 Machine switch
18 Button for height adjustment of
handle
19 Bracket for power cable
20 Flap for storage compartment
21 Water attachment
22 Carrying handle
23 Hose holder
24 Bracket for spray set
25 Holder for flat hose cassette
# Model plate
Electrical Specifications
RE 108
RE 118
RE 128 PLUS
Specifications
Power supply: 230 V / 1~ / 50 Hz
1)
230 V - 240 V
1~ / 50 Hz
2)
220 V / 1~ / 50 Hz
3)
110 V / 1~ / 60 Hz
4)
120 V / 1~ / 60 Hz
5)
Power output: 1.7 kW
1) 2) 3)
1.4 kW
4) 5)
Ampere rating: 8 A
3)
9A
1) 2)
13 A
4)
11.7 A
5)
Fuse: 10 A
1) 2) 3)
15 A
4) 5)
Protection class: I
Type of
protection: IP X5
Power supply: 230 V / 1~ / 50 Hz
1)
230 V - 240 V
1~ / 50 Hz
2)
Power output: 2.1 kW
1) 2)
Ampere rating: 9.2 A
1) 2)
Fuse: 10 A
1) 2)
Protection class: I
Type of
protection: IP X5
Power supply: 230 V / 1~ / 50 Hz
1)
230 V - 240 V
1~ / 50 Hz
2)
120 V / 1~ / 60 Hz
5)
220 V / 1~ / 60 Hz
6)
Power output: 2.3 kW
1) 2) 6)
1.4 kW
5)
Ampere rating: 10 A
1) 2)
13 A
6)
13.5 A
5)
Fuse: 10 A
1) 2)
15 A
5) 6)
Protection class: I
Type of
protection: IP X5
1)
230 V / 50 Hz version
2)
230 V - 240 V / 50 Hz version
3)
220 V / 50 Hz version
4)
110 V / 60 Hz version
5)
120 V / 60 Hz version
6)
220 V / 60 Hz version

Stihl RE 128 PLUS Specifications

General

Operating Pressure	135 bar
Water Flow Rate	500 l/h
Max Water Temperature	60 °C
Power Source	Electric
Power Consumption	2.3 kW
Mains Voltage	230 V
Frequency	50 Hz
Power Cord Length	5 m
Sound Power Level	85 dB(A)
