4 Safety Precautions
3 Handlebar
The handlebar is used to hold, guide and transport the
lawn mower.
4 Discharge flap
The discharge flap closes off the discharge chute.
5 Star grip nut
The star grip nut clamps the handlebar to the lawn
mower.
6 Fuel tank cap
The fuel tank cap seals the opening for adding petrol.
7 Filter cover
The filter cover covers the air filter.
8Spark plug
The spark plug ignites the fuel/air mixture in the engine.
9 Spark plug socket
The spark plug socket connects the ignition lead to the
spark plug.
10 Muffler
The muffler reduces the lawn mower's noise level.
11 Engine oil cap
The engine oil cap seals the opening for adding engine
oil.
12 Lever
The lever is used to set the cutting height.
13 Grass catcher box
The grass catcher box collects the mown grass.
# Rating plate with machine number
3.2 Symbols
The symbols can be on the lawn mower and have the
following meaning:
4.1 Warning Symbols
The warning symbols on the lawn mower have the following
meaning:
This symbol indicates the lawn mower weight.
Guaranteed sound power level in accordance
with Directive 2000/14/EC in dB(A) for the
purpose of comparing the sound emissions of
products.
This symbol identifies the fuel tank cap.
This symbol identifies the engine oil cap.
4 Safety Precautions
Follow the safety instructions and their
measures.
Read, understand and keep the instruction
manual.
Observe the safety instructions on objects
thrown up by the machine and their measures.
L
W
