Stihl RM 248 User Manual

0478-111-9647-A
51
English 19 Specifications
19.1 STIHL RM 248.1, RM 253.1 Lawn Mower
– Engine type:
– RM 248.1 : STIHL EVC 200
– RM 253.1 : STIHL EVC 200
– Displacement:
– RM 248.1 : 139 cm³
– RM 253.1 : 139 cm³
– Power:
– RM 248.1 : 2.1 kW (2.8 HP) at 2800 rpm
– RM 253.1 : 2.1 kW (2.8 HP) at 2800 rpm
– Speed:
– RM 248.1 : 2800 rpm
– RM 253.1 : 2800 rpm
– Maximum fuel tank capacity: 900 cm³ (0.9 l)
– Weight:
– RM 248.1 : 26 kg
– RM 253.1 : 27 kg
– Maximum grass catcher box capacity: 55 l
– Cutting width:
– RM 248.1 : 46 cm
– RM 253.1 : 51 cm
19.2 Blade
– Minimum thickness a: 2.0 mm
– Minimum width b: 55 mm
– Sharpening angle c: 30°
19.3 Sound Values and Vibration Values
RM 248.1
The K value for the sound pressure level is 2 dB(A). The K
value for the sound power level is 1.2 dB(A). The K value for
the vibration values is 1,40 m/s².
– Sound pressure level L
pA
measured in accordance with
2006/42/EC: 83 dB(A)
– Sound power level L
wA
measured in accordance with
2000/14/EC: 95.5 dB(A)
– Vibration value a
hv
measured in accordance with
EN 12096, handlebar: 2,80 m/s²
RM 253.1
The K value for the sound pressure level is 2 dB(A). The K
value for the sound power level is 1.4 dB(A). The K value for
the vibration values is 2.20 m/s².
– Sound pressure level L
pA
measured in accordance with
2006/42/EC: 84 dB(A)
– Sound power level L
wA
measured in accordance with
2000/14/EC: 96 dB(A)
– Vibration value a
hv
measured in accordance with
EN 12096, handlebar: 5.50 m/s²
For information on compliance with Employers' Vibration
Directive 2002/44/EC see www.stihl.com/vib.
19.4 REACH
REACH is an EC regulation and stands for the Registration,
Evaluation, Authorisation and Restriction of Chemical
substances.
For information on compliance with the REACH regulation
see www.stihl.com/reach.
19 Specifications

Stihl RM 248 Specifications

General

Type	Push lawn mower
Cutting width	460 mm
Grass catcher	Yes
Product color	Black, Orange
Uncertainty K	2 m/s²
Housing material	Steel
Number of wheels	4 wheel(s)
Rotational speed	2900 RPM
Maximum lawn area	1200 m²
Mulching function	-
Sound power level	96 dB
Vibration emission	4 m/s²
Engine displacement	139 cm³
Sound pressure level	83 dB
Front wheels diameter	- mm
Maximum cutting height	75 mm
Minimum cutting height	25 mm
Grass collecting volume	55 L
Power source	Gasoline

Weight and Dimensions

Weight	26000 g
