► Add the engine oil as described in the engine
instruction manual.
7 Refuelling the Lawn Mower
7.1 Refuelling the Lawn Mower
NOTICE
■ The lawn mower may be damaged if the cor‐
rect fuel is not used.
► See the engine instruction manual.
► Stop the engine.
► Place the lawn mower on a level surface.
► Clean the area around the fuel tank cap with a
damp cloth.
► Turn fuel tank cap (1) anti-clockwise until it
can be removed.
► Remove the fuel tank cap.
► Add fuel, stopping at least 15 mm short of the
fuel tank brim.
► Place the fuel tank cap on the fuel tank.
► Turn the fuel tank cap clockwise and tighten
firmly by hand.
The fuel tank is sealed.
8 Adjusting the Lawn Mower
for the User
8.1 Folding Up the Handlebar
► Stop the engine.
► Detach the spark plug socket.
► Place the lawn mower on a level surface.
► Fold up handlebar (1), ensuring that cables (2)
are not trapped.
► Screw in quick-clamping devices (3).
► Close quick-clamping devices (3) in the direc‐
tion of handlebar (1).
Handlebar (1) is firmly attached to the lawn
mower and quick-clamping devices (3) lie flat
against handlebar (1).
► Press control bar for mowing (4) to handle‐
bar (1) and hold.
► Slowly pull starter handle (5) in the direction of
starter rope guide (6).
► Hook starter handle (5) into starter rope
guide (6).
► Release control bar for mowing (4).
► Re-attach the spark plug socket.
8.2 Folding the Handlebar
The handlebar can be folded for space-saving
transport or storage.
► Stop the engine.
► Detach the spark plug socket.
► Place the lawn mower on a level surface.
► Press the control bar for mowing to the han‐
dlebar and hold.
7 Refuelling the Lawn Mower English
0478-111-9951-B 29
