Maintenance 5
Preparatory tasks for maintenance
1Max
2Min
Check and refill hydraulic oil
The required hydraulic fluid-
type is
• H-LP 46, DIN 51524
• Viscosity is 41.4 - 47 cSt
• The amount is about 0.7L to 1.
0L
ENVIRONMENT NOTE
Waste material like oil, used batteries or other
must be probably disposed and recycled
according to the national regulations and if
necessary brought to a recycling company.
Loosen the 2 screws for the main cover and
remove the cover.
The minimum and maximum allowed oil level
can be checked on the oil tank.
If necessary add oil at the filling point.
113
3 801 16 01 EN - 11/2018 59
