Technical data 6
Main technical data for standard ve
rsion
DESCRIPTION
1.4
Driving: ride-on standing mode (ride st.), pedestrian
mode (ped.)
Pedestrian
1.5
Rated capacity
Q(kg)
1500
1.6
Centre of gravity c (mm)
600
1.8 Distance from centre of load wheels to front forks
x (mm)
946
1.9
Wheelbase: Forks up/down y (mm)
1293
WEIGHT ECU 15C
2.1
Weight in running order (±10%) kg
200
2.2
Load per laden axle, traction end/load end (±10%) kg
520 / 1180
2.3
Load per unladen axle, traction end/load end (±10%) kg
160 / 40
WHEELS ECU 15C
3.1
Tyres: Pneumatic, polyurethane, rubber
Polyurethane (PU) /
Rubber
1)
3.2 Traction wheel sizes
Ø x w (mm)
Ø 200 x 70 (Ø 230
x 73)
1)
3.3
Wheel sizes, load end
Ø x w (mm)
Ø80x70
3.4
Additional wheels (dimensions) Ø x w (mm)
Ø80x30
3.5
Number of wheels at traction end/load end (x =
traction wheel)
1X+2/4
3.6
Track, traction end
b10mm 410
3.7
Track, load end
b11mm
380 (360, 525)
2)
DIMENSIONS ECU 15C
4.4
Lift (± 5 mm) h3 (mm)
115
4.9
Height of tiller in driving position, min/max. h14 (mm)
800 / 1170
4.15
Height of forks when lowered h13 (mm) 85 (80)
4)
4.19
Total length
l1 (mm)
1660
4.20
Length to front of forks l2 (mm)
510
4.21 Total width
b1/b2
(mm)
574
4.22
Dimensions of forks
s/e/l (mm)
48 / 160 / 1150
2)
4.25
Outside fork spread b5 (mm) 540 (520,685)
2)
4.32
Ground clearance in centre of wheelbase, min/max
m2 (mm) 37(32)
4)
113
3 801 16 01 EN - 11/2018 65
