Stirling EE-9248 - Using the Mop Function

Using the Mop Function
1. The mop is only to be used indoors on tiles, vinyl, lino or wooden floorboards.
Do not use the mop on carpet or uneven ground.
2. The mop function is not to be used with water. When the mop pad connects
with the surface of the floor it is able to pick up finer and smaller dust particles.
3. The velcro mop base is clicked onto the right & left hinges on the bottom of the
dust filter bracket (refer Fig.1).
4. You can then attach one mop pad to the velcro (refer Fig. 2).
5. To remove, unclick the velcro mop base from the right and left hinges on
the dust filter bracket (refer Fig. 3).
Do not use the mop function on carpet or uneven ground.
Fig. 3
Fig. 2
Do not use the vacuum cleaner or the mop function with water.
Getting Started Cont.
12
AFTER SALES SUPPORT
MODEL: EE-9248 PRODUCT CODE: 49631 06/2015
1800 898 750
AUS
service@wkfe.com.hk
Fig. 1
