Cleaning the Side Brush or Replacing the Side Brush
1. Release the screw in the main shaft of the side brush before changing.
2. Press the side brush against the main shaft and then fasten the screw (Refer
Fig. 1) to re-assemble.
Cleaning the Left/Right Wheels
1. Release the screw of the left/right wheel
with a screwdriver (Refer Fig. 1).
2. Take out the left/right wheel and clean
them with the brush (Refer Fig. 2). Don’t
wash in water.
3. Place the left/right wheel in the original
position and tighten the screw.
Other Useful Information Cont.
26
AFTER SALES SUPPORT
MODEL: EE-9248 PRODUCT CODE: 49631 06/2015
1800 898 750
AUS
service@wkfe.com.hk
Fig. 1
Fig. 1
Fig. 2
