Product Overview
Use the following diagrams and explanations to familiarise yourself with the
components of the robot vacuum cleaner and its accessories:
Top view
1 Infrared signal receiver
2 Display screen
3 Front bumper
4 Touch buttons
5 Dustbin release key
6 Air outlet release key
7 Air outlet
8 Dustbin
9 DC socket
10 Power switch
6
AFTER SALES SUPPORT
MODEL: EE-9248 PRODUCT CODE: 49631 06/2015
1800 898 750
AUS
service@wkfe.com.hk
Menu Display:
1. select the desired cleaning
day / days of the week
2. Wheel rotation/speed display
3. “EM” Engineering Mode
4. “Auto” cleaning display
5. “Spot” cleaning display
6. “Current” week
7. Malfunction display
8. Charging display
9. Battery life display
10. Time display
Touch Buttons:
11. Engineering Mode (refer page 13)
You are able to activate the below
cleaning modes without using the
remote control.
EM
12. Auto cleaning
13. Spot cleaning
1
3 4
5
10
9
7
2
6 8
E.M
11 13
12
3
5
6
7
8
1
2
4
9
10
