6 SpeedTech Lights, Inc © 2019
ALPHA
®
7x9
GRILLE / SURFACE MOUNT
All rights reserved. No part of this Instruction Manual may be reproduced, distributed, transmitted, or otherwise shared in any form or by any means,
including but not limited to photocopying, recording, electronic delivery, .PDF reproduction, or any other means of reproducing all or any part hereof without
the express prior written consent of SpeedTech Lights, Inc, except for non-commercial purposes as permitted by United States copyright law. Customers
of SpeedTech Lights, Inc, may download and print this Instruction Manual for use with products sold to the customer by SpeedTech Lights, Inc. However,
no part of this Instruction Manual may be otherwise or subsequently reproduced, downloaded, disseminated, published, or transferred, in any form or by
any means, except with the prior written consent of SpeedTech Lights, Inc.
Flash Pattern List
• Steady Burn
• Single Flash 75 FPM
• Single Flash 240 FPM
• Single Flash Left/Right 210 FPM
• Quad Flash 75 FPM
• Triple Flash Left/Right 150 FPM
• Triple Flash Top/Bottom 150 FPM
• Double Quadrant
• Inverted Double Quadrant
• Single Flash Left/Right 240 FPM
• Single Flash Left/Right 300 FPM
• Single Flash Double Quadrant
• Single Flash Inverted Double Quadrant
• Single Flash and Left/Right Combo
• 3x Single Flash Pulse
• Accelerating Single Flash Left/Right
• Accelerating Single Flash
• Accelerating Quadrants
• Steady Burn Right Side Single Flash Left Side 60 FPM
• Steady Burn Left Side Single Flash Right Side 60 FPM
• Steady Burn Left High Quadrant Single Flash Right Low Quadrant 60 FPM
• Steady Burn Right Low Quadrant Single Flash Left High Quadrant 60 FPM
• Steady Burn Right High Quadrant Single Flash Left Low Quadrant 60 FPM
• Steady Burn Left Low Quadrant Single Flash Right High Quadrant 60 FPM
• Steady Burn Left Side Triple Flash Right Side 90 FPM
• Steady Burn Right Side Triple Flash Left Side 90 FPM
• Single Row Clockwise Sweep
• Single Row Counter Clockwise Sweep
• Single Row Clockwise Sweep with Pulse
• Single Row Counter Clockwise Sweep with Pulse
• Single Flash 60 FPM
Flash Pattern Shortcuts
• Hold for 3 seconds to toggle Steady Burn mode.
About Flash Patterns
• All STL LED products are equipped with a non-volatile memory which will recall the last ash pattern when the Light Bar is turned on.
• Set the ash pattern by pushing the Flash Pattern button on the Grand Control Box to cycle through the various patterns.
• If you are not using the Grand Control Box, follow the wiring diagram to identify the Flash Pattern wire to manually cycle through patterns.
