STMicroelectronics B-G431B-ESC1 User Manual

UM2516 Rev 4 11/29
UM2516 Hardware layout and configuration
28
5 Hardware layout and configuration
5.1 Block diagram
The B-G431B-ESC1 Discovery kit is a complete hardware platform (power and control)
based on several ST products as shown in the following block diagram:
Figure 5. Block diagram with ST products
The top side is mainly dedicated to the power section. It is composed of power MOSFETs,
gate drivers, and a DC-DC converter.
Figure 6. B-G431B-ESC1 top view
