5 | Installation
20
07/2023 | ID 443360_en.00
Tightening torques for the locking screw (11)
The tightening torques for the locking screw are in line with the size of the ME adapter on the gear unit input and the
diameter of the motor shaft.
Type d2 KS s M
A
[mm] [mm] [Nm]
_ME10 d2≤14 M5 4 5.9
_ME10 14<d2≤19 M6 5 10
_ME20 d2≤19 M6 5 10
_ME20 19<d2≤24 M8 6 25
_ME30 d2≤24 M8 6 25
_ME20 24<d2≤32 M10 8 49
_ME30 24<d2≤38 M10 8 49
_ME40 d2≤38 M10 8 49
_ME40 38<d2≤48 M12 10 85
_ME50 55<d2≤60 M16 14 210
Abbreviations used:
§ KS = Nominal diameter of the locking screw (11)
§ M
A
= Tightening torque for the locking screw (11)
§ s = Size of the hexagon insert (3)
§ d2 = Motor shaft diameter
5.2.4 Mounting the motor on a gear unit with MB adapter
The assembly of a motor on a gear unit with an MB motor adapter with brake is described in a separate document (see
Supporting documents [}5]).
5.3 Mounting drive elements on a solid shaft
This chapter describes the assembly of drive elements, such as hubs, belt drives, couplings, pinions or sprockets, on the
output of a gear unit with a solid shaft and feather key.
When mounting drive elements on a solid shaft without a feather key, observe the technical documentation of the drive
element in question.
ATTENTION!Damage to encoders, bearings and shafts due to improper assembly! Never use force when mounting drive
elements with fittings, e.g. hitting drive elements, shafts or the motor or gear housing with a hammer, and instead install
them in accordance with the instructions in the documentation.
Prerequisites
§ The drive element does not cause any impermissible shaft loads (e.g. tensioning the belt on a belt drive). Information
on permissible shaft loads can be found in the corresponding catalog (see Additional documentation [}12]);
§ The drive element is balanced;
§ The tolerance of the inner hole of the drive element is ISO H7;
§ The keyway of the drive element corresponds to DIN 6885-1 (if not otherwise specified);
