STONEX S7-S - CHAPTER 4: CONNECTING TO A PC

39
Screen
Use the Screen control to align the touch screen or to change the appearance of text on the
screen. To open the Screen control:
 Tap / Settings / System / Screen.
To change the screen settings (as shown in Fig. 3.6.8):
1. Tap the General tab.
2. To change the orientation of the screen select an option in the Orientation group.
3. To start the alignment sequence for the touch screen, tap Align Screen.
4. Tap OK.
Figure 3.6.8 – Changing screen settings
Using ClearType font smoothing can make text easier to read on the screen.
To enable ClearType:
1. Tap the ClearType tab and then select the
Enable ClearType check box.
2. Tap OK.
To change the size of text on screen:
1. Tap the Text Size tab.
2. Tap and drag the slider control to the left to
make text smaller or to the right to make
text larger.
The example text below the slider shows
how the text will appear on screen.
3. Tap OK.
Figure 3.6.9 – Changing text size
