Method 1: Without housing unit
(between 2 base units)
Before installing the appliance, check
the internal dimensions as shown
opposite.
The space for the appliance must be
clear of obstructions and there must be
enough space at the back of the oven
for the gas inlet pipe to hang freely.
You may have to cut into or remove
any rear cross members from the
housing unit to obtain the 570mm
minimum depth.
The fixing kit
is packed onto the oven
under the polystyrene packaging. You
will find 2 side trims (692mm long)
and 4 runners (420mm long). The
fixing screws are in a polythene bag
in the oven pack.
1. Take the 6 No 8 x 12mm long self
tapping (silver) screws from the
polythene bag, and use them to fit
one runner to each side of the
appliance.
2. Make sure they are the right way
up as shown.
3. Take one of the side trims, hold it
against the side of the base unit,
and mark off 692mm from the top
edge of the base unit, to the top
edge of the runner.
Note: This ensures a 5 - 8mm
clearance from the underside of the
worktop to the top of the appliance.
4. Measure 50mm from the front
edge of the base units, to mark the
front edge of the runners.
5. Take 6 of the No. 8 x 12mm
(black) chipboard screws and
screw the runners into position the
right way up as shown.
6. Fit the side trims to be flush to the
top and front edges of the base
units, using the remaining 6
No. 8 x 12mm (black) chipboard
screws.
18
INSTALLATION INSTRUCTIONS
