11.08

Strapex STB 65

Pos. Artikel-Nr. Benennung Part name Article Articolo Stück

Part no Quantity

No d‘article Pièce

Art. nr. Pezzi

100 1832.011.136 Deckel Spannen Cover tensioning Couvercle tension Coperchio tensione 1

101

102 1832.042.030 Bandführung, 16 mm Strap guide, 16 mm Guide de la bande, 16 mm Guida reggia, 16 mm 1

103 1911.804.164 Senkschraube, M4 x 16 Counter sunk screw Vis noyée Vite a testa svasata 1

104 1911.804.126 Senkschraube, M4 x 12 Counter sunk screw Vis noyée Vite a testa svasata 3

105

106

107

108

109 1832.031.027 Wippenhebel komplett, inkl. Pos. 111-113 Rocker lever complete, incl. pos. 111-113 Levier de basc. compl., incl. pos. 111-113 Leva del bilanciere completo, incl. pos. 111-113 1

110

111 1821.039.024 Gewindebolzen, M8 Threaded bolt Goujon ﬁ letée Perno ﬁ lettato 1

112 1922.104.303 Passkerbstift, Ø4 x 30 Ridget pin Goupille cannelée Spina scanalata 1

113 1922.104.300 Zylinderkerbstift, Ø4 x 30 Cylinder pin Goujon cylindrique Spina cilindrica 1

114 1832.031.018 Sperrklinke Blocking pawl Cliquet de verrouillage Nottolino di blocco 1

115 1821.031.048 Bolzen Bolt Goujon Albero 1

116 1832.039.190 Zahnsegment Toothed segment Segment dentée Supporto dentata 1

117 1917.411.105 Passscheibe, Ø10/16 x 0.5 Spacer disk Rondelle de calibrage Vite calibrata 2

118 1920.108.102 Sicherungsscheibe, Ø8 Retaining ring Circlip Rondella di sicurezza 1

119 1911.004.254 Zylinderschraube, M4x25 Cylinder screw Vis cylindrique Vite cilindrica 1

120 1821.036.003 Zugfederbolzen Tension spring bolt Goujon pour ressort à tension Albero di molla di torsione 1

121 1821.011.021 Zugfeder Tension spring Ressort à tension Molla di torsione 1

122 1832.022.153 Kurvenbolzen kompl., inkl. Pos. 128,129,143 Cam bolt complete, incl. pos. 128,129,144 Goujon de came compl. pos. 128,129,144 Albero a camme completo, pos. 128, 129,144 1

123 1925.010.802 Kugel gehärtet, Ø8 Globule hardened Bille trempé Palla invecchiare 1

124 1821.010.052 Druckfeder Compression spring Ressort à pression Molla di compressione 1

125 1832.011.156 Gewindbolzen, M10 Threaded bolt Goujon ﬁ leté Perno ﬁ lettato 1

126 1821.010.058 Druckfeder Compression spring Ressort à pression Molla di compressione 1

127 1832.022.124 Schweisstasten-Set, inkl. Pos. 156 Welding button-set, incl. pos. 156 Touche soudage, incl. pos. 156 Tasto di saldatura, incl. pos. 156 1

128

129

130 1832.022.117 Kurve Cam Came Camme 1

131 1910.605.082 Gewindestift, M5 x 8 Set screw Goujon ﬁ leté Perno ﬁ lettato 1

132 1821.151.004 Mikroschalter, Schweissen Micro switch, welding Microinterrupteur, soudage Micro interruttore, saldatura 1

133 1912.401.104 Linsenschraube, M2 x 10 Oval head screw Vis à tête bombée Vite a testa bombata 2

134 1832.031.043 Unterlegeplatte Shim plate Plaque entretoise Piastra d‘appoggio 1

135 1832.022.091 Federbügel Spring bow Bride à ressort Molla 1
