1.4. X7-E1608 SPECIFICATIONS
Items Technical Index
Product Series X7-E1608
Function Overview Preview, Recording, Playback, Network, Locating
System
OS Linux 3.0.8
Control Mode CP4, Easy Check, IR Remote Control, Network
Video
Input 16 channels WD1+4channels IPC（720P）
Output 2 channels
Total Resource 400FPS WD1 @ PAL/480FPS WD1@NTSC +120FPS 720P
Video Signal Standard
Electrical level:1Vpp Impedance:75Ω
NTSC/PAL Optional
Audio
Input 16 channels
Output 2 channels
Audio Signal Standard
Electrical level:2Vpp Input impedance:4.7kΩ
Display
Display Split 1/4/9 Image display
OSD Locating, alarm, vehicle number, speed and date/time
Operation Interface Graphical User Interface
Recording
Video/Audio
Compression
H.264/ADPCM
Image Resolution
Analog:
PAL:WD1(960X576), WHD1(960X288),
WCIF(480X288), D1(704X576), HD1(704x288),
CIF(352x288);
NTSC:WD1(960X480), WHD1(960X240),
WCIF(480X240), D1(704x480), HD1(704x240),
CIF(352x240);
Digital:720P(1280X720)
Image Quality 8 levels adjustable
Recording Mode
Boots up/manual/schedule/Alarm event recording(sensor
trigger, speed, external acceleration sensor, alarm button)
Pre-recording 0-60 minutes
Post-recording 0-30 minutes
Mirror Recording Yes
Playback
Playback Channel
1/4 channels by local playback, 1/4/8 channels playback
sync by PC software
Search Mode Date/time, channel, event
Network
Ethernet RJ45(1000M)x2
WIFI
Supports（802.11b/g/n）
3G/4G EVDO/WCDMA/TDD-LTE/FDD-LTE
Locating GPS Location tracking, speed detection and time sync
Storage Hard disk 2.5" SATA hard disk x 2
