Streamax X7-E1608 - External Interface

User Manual for X7-E1608
For more information, please visit our website www.en.streamaxtech.com
11
Interface
USB USB 2.0 x 2 (1 at front panel, 1 at rear panel)
SD SD x 1
Sensor 8 inputs, 2 outputs
Speed 1 channel pulse speed detection
Interface Control panel (CP4)(Optional)
Power
Input DC8-36V
Output 12V@1A, 5V@1A
Current
Impulse current: input 13.5V@10A
Working current: input 13.5V@5A input 27V@2.5A
Standby current: 0A
Physical
Characteristic
Dimension
(L x W x H)
229mmx327mmx122.5mm
Weight 5.5Kg
Operating
Environment
Temperature
-25℃ ~ +60℃
Relative Humidity 8%~90%
Certificates CE, FCC, MIL-STD-810F
1.5. EXTERNAL INTERFACE
Dimension(Unit: mm)
