User Manual for X7-E1608
For more information, please visit our website www.en.streamaxtech.com
8
Rear Panel:
Unit: (mm)
Specification
Items Specification
Video
IPC Channel 4 channels
Interface RJ45(10M/100M)
IPC Power Supply POE
Power
Interface M12(9 Pin)
Power Input DC 8—36V
Power Standard ISO 7637-2
Network Port RJ45(10M/100M)
Status LED
6 PCS The yellow light is about power status,
while the green lights (5 PCS) are about
network working status.
Protection Class IP54
Physical Characteristics Dimension (L x W x H) 149mm(L) x 100mm(W) x 38mm(H)
Environment
Operating Temperature
Working Temperature-40℃-+70℃
Storage Temperature:-40℃ ~ 85℃
Anti-vibration Standard MIL-STD-810F
