14.1 1 Burner /fan/gas pipe/heat exchanger/casing Spare S-CB 60 - S-CB 120
Spare parts S-CB60/120 Duo-Z GB
Article-name Order code . Article name Order code
1 Front panel 31 Burner control F-910 E04.016.277
4 Seal ring 80 mm E07.004.023 32 Tube gland siphon
4 Seal ring 100 mm E07.004.024 33 Tube gland ø38 mm E04.010.033
4 Seal ring 130 mm E07.004.025 34 PG-9 swivel + cable gland 8mm E05.000.064
5 Air inlet connection excentr 80 E01.008.002 35 Adapter concentr. 80/125 E01.008.010
5 Air inlet connection excentr 100 E01.008.003 35 Adapter concentr. 80-100/150 E01.008.012
5 Air inlet connection excentr 130 E01.008.004 35a Gasket flue gas outlet 194/150
5a Gasket air inlet connection 162/135 36 Seal ring 80 mm E07.004.023
6 Automatic air vent E04.015.008 36 Seal ring 100 mm E07.004.024
7 Seal ring 80 mm E07.004.023 37 Seal ring 125 mm E07.004.026
7 Seal ring 100 mm E07.004.024 37 Seal ring 150 mm E07.004.027
8 NTC sensor E04.016.287 38a Gasket flue gas outlet 194/150
9 Insulation burner chamber E07.010.098 40 Adapter flue gas outlet 80/80 E01.008.014
10 Heat exchanger 6+3 40 Adapter flue gas outlet 80/100 E01.008.008
10 Heat exchanger 8+4 40 Adapter flue gas outlet 100/130 E01.008.009
10 Heat exchanger 10+6 41 Seal ring 80 mm E07.004.023
11 NTC sensor E04.016.287 41 Seal ring 100 mm E07.004.024
12 Insulation burner door E07.010.093 41 Seal ring 130 mm E07.004.027
13 Burner door E03.010.013
14 Nuts M6 E06.010.012
15 Electrode E04.009.014
15 Gasket electrode E07.001.024
16 Burner 6+3 E04.012.025
16 Burner 8+4 E04.012.026
16 Burner 10+6 E04.012.027
17 Gasket burner inlet pipe E07.001.029
18 ø5x14 mm Torx screw
19 M5x12 DIN7985 screw
20 Gasket inlet pipe & fan A60
20 Gasket inlet pipe & fan A80 / A100
20 Gasket inlet pipe & fan A120
21 Fan E04.016.132
22 O-ring 70x3 mm E07.002.007
23 Air gas mixing plate A60 / A80
23 Air gas mixing plate A100 / A120
24 Pipe coupling ¾"x ¾"
25 Gasvalve A60 / A80 E04.016.014
25 Gasvalve A100 / A120 E04.016.281
26 O-ring 33,4x2 NBR E07.002.018
27 Siphon 90 mm grey
27a Siphon cleaning tube grey
28 Flexible tube 600 mm grey
29 On/off switch black
30 Display-unit DU-910 incl. cable E04.016.278
