Strong SRT 5203 - Page 20

PART 1 • English
17
English
Loop through frequency range: 47 ~ 862 MHz
Input signal level: -82 ~ -20 dBm
Memory and System
Flash memory: 1 MByte; SDRAM: 16 MBytes
Multimedia
Video playback: MPEG-1 and MPEG-2 encoded (mpg)
Audio playback: MP3 and WMA formats
Picture view: JPEG format
Connectors
ANT IN: IEC 169-2 Female
TO TV: IEC Male; TV SCART (RGB, CVBS)
VCR SCART: Composite Video, Audio L/R
S/PDIF: coaxial output
USB 2.0 port, max. 5 V / 500 mA supported
General Data:
Supply Voltage:
220 – 240 V AC (SMPS), 50/60 Hz
Power Consumption:
SRT 5203 – typ. 4.5 W, max. 8 W;
SRT 5222 – typ. 6.5 W, max. 9 W
Power consumption in Standby: < 1 W;
Operating Temperature: 0 ~ +40 °C
Storage Temperature: -30 ~ +80 °C
Operating Humidity Range:
10 ~ 85 %, RH, Non-condensing
Size (W x D x H) in mm:
SRT 5203: 180 x 135 x 43
SRT 5222: 234 x 135 x 43
Weight:
SRT 5203: 0.46 kg;
SRT 5222: 0.57 kg
* STRONG cannot guarantee the playback of external video files, which have not been recorded by this device
