PART 1 • English
19
English
3. System and memory
CPU: CT216 32-bit RISC CPU
CPU Speed: 108 MHz
Flash memory: 16 Mbits
SDRAM: 64 Mbits
4. A/V & Data In/Out
TV Scart Output: RGB, CVBS, Audio L/R Output with Volume Control
VCR Scart Input/Output:
1
Input: CVBS, Audio L/R
Output: CVBS, Audio L/R Output with Volume Control
3 RCA Video and Audio output: Yellow: Video output; White: Audio Left; Red: Audio Right
S/PDIF output:
1
Digital audio output, coaxial
Data Interface: RS-232, Bit Rate: 115200 baud
Connector: 9-Pin D-Sub Male type
5. Power Supply
Input Voltage: 90 ~ 240 V AC, 50/60 Hz +/-5%
Power Consumption: Max. 20 W
Stand-by Power: <=8 W
6. General Data
Size(WxHxD): 260 x 40 x 210 mm
Weight: 1.2 kg
Operating Temperature: 0 ~ 40 °C
Storage Temperature: -30 ~ 80 °C
Operating Humidity Range: 10 ~ 85 % RH, Non-condensing
Storage Humidity Range: 5 ~ 90% RH, Non-condensing
