6.3 Programme Information (Info banner)
Programme information is always displayed for a certain period of time whenever you switch channels.
You can also view the programme information by pressing the INFO button while watching a
programme, or consult the information of the other channels by pressing pq buttons.
Press EXIT to hide the info banner.
Info banner:
n Indicates channel number and name
n Indicates current time
n Informs about current programme name
n Indicates name of the next programme
n Provides video and audio parameters for broadcasted programme
6.3.1 Extended information panel
To access the extended information, press INFO button:
n once during presence of the information banner on screen
n twice in viewing mode.
The details of the current programme information (name and description of the current programme)
will be provided in an additional window*. If the programme description does not fit in the display area,
you can use pq to scroll through this information. It is also possible to see the info regarding the next
program scheduled by pressing t u. Press EXIT to close extended information panel.
NOTE: You can change the on-screen duration of the info banner in the User
Setting > Display menu. Please refer to section 8.3.2 for more details.
* Information will be displayed if available. Availability depends on the broadcaster.
6.4 Selecting audio language
Some channels support a choice of audio formats and/or languages.
Press AUDIO in viewing mode to display a list of available audio languages.
Use pq to highlight the language of choice and press OK to confirm.
In the same menu it is also possible select with Teletext subtitle and DVB subtitles as well as DVB audio. To
change selection use the t u buttons.
6.5 Selecting subtitle language
Press SUB in viewing mode to display a list of available subtitle languages. Use pq to select the subtitle
language and press OK to confirm. Additionally you can adjust your preferred subtitle language as
described in chapter 8.3.1.
NOTE: Please consider that this function supports DVB and TXT subtitles and this
selection only displays them temporarily. Subtitles may not be supported
by every channel or broadcaster.
6.6 Viewing the teletext
To access the teletext, press the TEXT button in viewing mode. Use 0~9 or pq buttons to select the
number of the page you wish to see. Press EXIT to go back to viewing mode.
10

Strong SRT7807 Specifications

Demodulator

demodulation	QPSK, 8PSK
input symbol rate	1 ~ 45 Ms/s
FEC decoder DVB-S2 QPSK mode	1/2, 2/3, 3/4, 5/6, 7/8
FEC decoder DVB-S2 8PSK mode	1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10

Video

video standard	MPEG-2, MP@ML, MP@HL, MPEG-4, AVC/H.264 MP@L4.2, HP@L4.2
max video resolution	1080p
aspect ratio	4:3 and 16:9
video resolution HDMI	576i/576p, 720p, 1080i, 1080p
video resolution SCART	PAL

Audio

audio standard	MPEG-1, MPEG-2 layer I&II

Tuner

tuner type	F Type, IEC169-24, Female 75ohm
input frequency range	950 – 2150 MHz
signal level	-60 to -25 dBm
LNB power	13/18 V DC (+/- 1 V)
DiSEqC version	1.0/1.1/1.2

System Memory

CPU	M3528 2000DMIPS
flash memory	28 MB NAND Flash
system memory	256MB DDR3

Connectors

SAT IN	present
S/PDIF (coaxial)	present
smartcard reader	1x, on right side panel
HDMI 1.4b	present
TV SCART	CVBS only
Ethernet (RJ45)	present
IR (infrared)	1x38KHz IR, NEC Protocol
power adapter	12 V/1.5 A
USB 2.0 port Type A	1x, 5 V/500 mA (max.) supported (with duster cover)

General Data

supply voltage	AC 100 - 240 V 50/60 Hz
input voltage	DC 12 V, 1.5 A
size (W x D x H)	168 x 99 x 39 mm
net weight	0.5 kg
